900 Novy Pureline Compact Stainless Steel
900 Novy Pureline Compact
Stainless Steel
Cooker hoods in the Novy Pureline Compact collection offer maximum efficiency whilst remaining extremely quiet. These sleek ceiling extractor hoods feature integrated dimmable LED lighting which can be adjusted from warm white to neutral white.
Flexible installation is a possibility thanks to a compact motor, for a built-in height of only 19.5 cm, which rotates in several directions. Designed to be externally ducted, however, recirculation is available with a Novy Recirculation Box.
Product Features and Specifications
|
Height (Min / Max) mm
|
195
|
|
Depth (mm)
|
508.00
|
|
Width (mm)
|
868
|
|
Noise (db)
|
59
|
|
Colour
|
Stainless Steel
|
|
Energy Rating
|
B
|
|
Number of Speed Settings
|
3 + Power
|
|
Control Method
|
Push Buttons & Remote Control
|
|
Remote Control
|
Standard
|
|
SKU
The unique, machine-readable identifier for a variation.
|
N6810
|
|
Weight (kg)
|
21.00
|
|
Voltage
|
230
|
|
Light Power (W)
|
12
|
|
Maximum Power (W)
|
171.00
|
|
Energy Efficiency Index EEI
|
65.4
|
|
Fluid Dynamic Efficiency Class
|
A
|
|
Fluid Dynamic Efficiency FDE
|
25
|
|
Flow Rate at BEP
|
322.5
|
|
Static Pressure at BEP
|
377
|
|
Electric Power Input at BEP
|
135
|
|
Time Increase Factor F
|
1.1
|
|
Lighting Efficiency Class
|
A
|
|
Lighting Efficiency LE
|
25
|
|
Grease Filtering Efficiency Class
|
D
|
|
Grease Filtering Efficiency GFE
|
67
|
|
Width (mm)
|
868.00
|
|
Depth (mm)
|
508.00
|
|
Height with Ceramic Hobs (Min-Max) (mm)
|
600 - 1600
|
|
Height with Gas Hobs (Min-Max) (mm)
|
650 - 1600
|
|
Functional Lighting Type
|
LED
|
|
Functional Lighting Dimmable
|
Yes
|
|
Number of Functional Lights
|
4.00
|
|
Effectiveness Of The Hob Light
|
401
|
|
Annual Energy Consumption AEC
|
62.7
|
|
Standard Annual Energy Consumption SAEC
|
62.7
|
|
Nominal electric power input of the lighting system
|
11.5
|
|
Extracted air flow in setting 1 at working point
|
244
|
|
Extracted air flow in setting 2 at working point
|
443
|
|
Extracted air flow in setting 3 at working point
|
581
|
|
Extracted air flow in setting boost at working point
|
650
|
|
Noise value extracted air setting 1 sound power level
|
38
|
|
Noise value extracted air setting 3 sound power level
|
59
|
|
Noise value extracted air setting boost sound power level
|
63
|
|
Power Consumption in Standby Mode (Ps) (W)
|
0.25
|
